4K Electronic Digital Microscope 60MP 48MP 1080P Microscope HDMI USB Video Microscope Software Flexible Articulated Arm

HDMI connects to the Monitor

1. It Can capture pictures and videos and save them on TF cards
2. 4K (30fps) /1080P(60pfs) MOV video is available

USB connection to computer

1. Install the ImageView on your computer
2. Through the ImageView program, you can get point spacing, parallel lines, vertical lines, line spacing, Angle, circle, radius, radian, rectangle, ellipse, concentric circles, center distance, and other measurement tools.

4K 60MP HDMI USB ULTRA HD BLACK CAMERA:

Software Download Address(working on Windows 10 and under Windows 10, software is not suitable for Apple computers) https://drive.google.com/file/d/19ZvEU5O9uayVsi1dgsJTA-08-XyHPPEW/view?usp=sharing

Sony Chip: IMX415L
Video Interface：HDMI USB-PC TF Card
Record：4K/1080p
Photo：Max 60MP(10368×5888)/4K
HDMI:4K/1080p
USB:4K/2K/1080p
Lens:CS
working voltage:12V
working current:190mA
optical format:1/2.7″
pixel size:1.5um*1.5um
scanning mode:progressive
shutter mode:electronic shutter”
dynamic range:69dB
S/N radio:40dB
OSD language:9 languages: Chinese/English/Japanese/French/Spanish/Italian/Portuguese/Russian/Arabic
AWB mode:One-shot white balance/manual/auto
Cross:Support 4 groups: 32 horizontal and vertical lines
line:Color/line width adjustable”
B/W:√
negative:√
mirror flip:√
Freeze:√

Feature:
Output Interface:HDMI USB two output
Sensor: Sony 1/2.7 Inch CMOS Sensor
Housing:Aluminum Alloy
Image Resolution:16MP/21MP/36MP/48MP/60MP/4K/1080P/720P(Use TF card)
Video Display:HDMI Monitor or USB PC
Video Record Resolution:4K/3840×2160@30FPS 1080p/1920×1080@60FPS 720p/1280×720@60FPS(Use TF card)
USB2.0(Drivefree) Record Resolution:1920*1080@30FPS/1280*720@30FPS/640*480@30FPS
HDMI Video Resolution:1920*1080@60F/S 3840×2160@30F/S 1280×720@60F/S
HDMI Scale:Support 4:3,16:9,16:10,Screen
Image and Video Storage:Support
Image and Video Playback:Support
Exposure:Auto Exposure and Manual Exposure(AE value set 0-12)
TF Card Flash Drive:MAX 128GB
Digital Zoom:1-4X
Video Format:MP4
Image Format:JPG
Camera Interface Mounting Diameter:25mm
Camera Interface Standard:C Mount
Lens Interface:25mm C/CS mount
White balance:One key white balance,Manual balance
Color:Black and White/Color
Dynamic Range:69dB
S/N Radio:40dB

Scanning Mode:Progressive
Shutter Mode:Electronic Shutter
Negative:Support
Mirror:Horizontal Mirror and Vertical Mirror
B&W Pictures:Support
Image Freezing:Support
R.G.B Adjustment:Support
Avoid Flicker:50Hz 60Hz
TF Card Formatting:Support
Remote:Infrared Remote Control
Cross Lines:4 Group ,32 Lines.Can set color& width& position,direction
Crosshair:Can adjust color, line size
Power:DC 12V/1A

48MP HDMI USB BLUE CAMERA:

Can work on Windows 10 and under Windows 10, MacBook.
software address: https://drive.google.com/file/d/1uhIXHPESUhsn4dt3KSQ0sBGb4_ta6aWO/view?usp=sharing

Model: Camera with HDMI USB2.0 two output
Image sensor: 48 megapixel SONY sensor
Frame rate: 1920*1080 60F/S @ HDMI output
Video save Movie size:4K(25fps) 2K(30fps) 1080P(60fps) 720P(60fps)(Note: If you need to record 4K or 2K video, you need to use the SDHC class10 TF card.)
Housing: All metal
Support:C-Mount lens
Digital magnification: 5 times digital zoom
White balance: Auto/manual
Cross cursor: Support multi-color, size adjustable
TF card interface: Max 16G
video format:MOV
HDMI interface: HDMI/USB output
Image : 48M 8000X6000/38M 7168X5376/26M 5888X4416/20M 5120X3840/16M 4608X3456
Language:Chinese/English
Mirroring: Support
Frequency:50Hz/60Hz
Monitor:16:9/16:10/4:3
Grid line: 15 Horizontal line, 15 Vertical line, Central scale line,Custom colors,Size
Power supply:5-12V 1A
