Nema23/34 Stepper Motor Fixed Shaft Screw Integrated Electric Cylinder Push Rod 100/150/200Mm Stroke for Precision Positioning

  • SKU: N/A
Nema23/34 Stepper Motor Fixed Shaft Screw Integrated Electric Cylinder Push Rod 100/150/200Mm Stroke for Precision Positioning
Roll over image to zoom in
Click to open expanded view

Price range: 585,99 € through 958,99 €

Sold By: MostiOne Team
Clear
SKU: N/A Category:

1*100/150/200/250mm electric cylinder



42 Electric Cylinder Technical Parameters:

Phases:2 phases
Step angle:1.8°
Rated voltage:2.5V
Rated current:2.5A
Rated resistance:0.80Ω±10%
Rated inductance:1.8 mH±20%
Holding torque:0.5 Nm
Lead screw diameter :6.35 mm
Lead:6.35 mm
Linear travel per step:0.03175 mm
Insulation class:B
Insuation resistance:100MΩ（500VDC）
Operating temperature:-20℃~+50℃
Heat rise:80K

57 Electric Cylinder Technical Parameters:

Lead screw diameter:Ø9.525mm
Lead screw lend:6.35mm
Linear travel per step:0.03175mm
Motor’s Phases:2 phases
Step angle:1.8°
Holding torque:1.8Nm
Rated voltage:3.8V
Rated current/phase:4A
Rated resistance/phase:0.95Ω±10%
Rated inductance/phase:4.5hm±20%
Insulation class:B
Insuation resistance:100MΩ（500VDC）
Operating temperature:-20℃~+50℃
Heat rise:80K














Additional information

Color

57 Step Body 56, 57 Step Body 76, 42 Step Body 48, 42 Step Body 34
Dimensions

250Mm Stroke, 150Mm Stroke, 100Mm Stroke, 200Mm Stroke
Set Type

Diameter 8Mmlead 2Mm, Diameter 8Mmlead 8Mm
